MAX CAPACITY: 32, 4 GPM ( 122, 6 LPM) ; MAX PRESSURE: 300 PSI ( 20 BAR)
Application
- - Chemical processing
- - Pharmaceutical industries
- - Injection and transfer applications of acids and solvents
- - Trademarked design
Features
- - Heavy duty stainless steel gear pumps for optimum chemical capability
- - Back pull-out design for easy maintenance without disturbing piping
- - One-piece " D " style bushings eliminate the need for wearplates and provide positive alignment and gear support
- - Capable of operating at nominal motor speeds
- - Good for up to 300psi differential pressures
- - No integral relief valve available, external relief recommended
Option
- Various drive arrangements available. Close-coupled bracket and magnetic drive arrangements available for the small series.
Material Of Construction
Housing : 316SS or ASTM A743
Gears / Shaft : 17-4pH SS or ASTM A564 Type 630
Bearings : Carbon Graphite or Silicon Carbide ( Opt)
Seal O' Rings : PTFE
